VİVA – VIRENT BIOCLIMATIC
TECHNICAL FEAUTURES:
-VİVA-VİRENT is the best roof opening solution for the social venues such as restaurants, hotels and cafes where smoking is prohibited.
-Viva-Virent provides vertical folding and reverse roundup together. Due to its bioclimatic feature, it enables % 100 ventilation.
-Viva-Virent is one of the utmost folding product among the current systems. It provides ventilation, utilising from the day light and shading as desired through its up to 105 degrees opening and vertical folding back panels. It provides %70 of the total area as open ventilation area when folded.
-Viva-Virent has a high insulation performance due to epdm joint systems. It has up to 235 kg per squaremeter snow bearing capacity.
-Viva-Virent panels, due to its panoramic folding movement, provides shading while ventilating from the roof.
-The system can provide fresh air in 30 degrees open position without being affected by snow or rain due to its profile design.
-The external cleaning of the panels can be performed from inside the space with no need to climbing on the roof.
-System, may bear up to 140 km/hour wind speed when it is folded.
-All the electrostatic ral chart colours are available for this product. Due to the electrostatic oven drying the colours last long.
-VİVA-VİRENT is the best roof opening solution for the social venues such as restaurants, hotels and cafes where smoking is prohibited.
-Viva-Virent provides vertical folding and reverse roundup together. Due to its bioclimatic feature, it enables % 100 ventilation.
-Viva-Virent is one of the utmost folding product among the current systems. It provides ventilation, utilising from the day light and shading as desired through its up to 105 degrees opening and vertical folding back panels. It provides %70 of the total area as open ventilation area when folded.
-Viva-Virent has a high insulation performance due to epdm joint systems. It has up to 235 kg per squaremeter snow bearing capacity.
-Viva-Virent panels, due to its panoramic folding movement, provides shading while ventilating from the roof.
-The system can provide fresh air in 30 degrees open position without being affected by snow or rain due to its profile design.
-The external cleaning of the panels can be performed from inside the space with no need to climbing on the roof.
-System, may bear up to 140 km/hour wind speed when it is folded.
-All the electrostatic ral chart colours are available for this product. Due to the electrostatic oven drying the colours last long.
Resim
Technical Feautures :
| Main Carrier : | Aluminium Profile |
| Roof Cover : | Special design 28 cm aluminium panel |
| Width : | Max 7 m at single system |
| Length : | Max 10 m at single system. |
| Control : | Remote Control |
| Motion : | 2 tube motors providing vertical and pull motion |
